Technical specifications

Model	BM10
Screen Size	2.4 inch   LCD display
Screen Resolution	320'240RGB
Image Resolution	320'240  QVGA
Video Frame Rate	15 25FPS
Si1nal intensity	4 Laval
Volume Control	5 level
intercom	Two-way communication
Voice control	Auto
Tansmission Frequency	2.4GHz ISM Band
While working method	FHSS
Denomination Power	19dBmOCW mode
Tansmission Speed	3Mbos
Transmission Range	200-300 meters in an open area
working current	TX,400mAMA RX: 400mA MAX , Stand-by: I60MA without charging current
Real sensitivity	-96dBm@BER=le-3
Charging current	120-200MA
Audio collect speed	16K
Audio Frequency  Response rang	120Hz-3KHz
MIC input	35- 50d8@
Total Harmonic distortion	<5.0%
Signal to noise ratio	46dB
Night Vision Range	2-3me
Working • Humidity	20-80%RH
Working  Temperature	0℃ --45℃



Attention: Obstructions like walls/doors/glasses/trees will significantly affect the transmission range.
supports long-distance digital transmission up to 200m( 660ft ) ~ 300m( 1000ft ) in empty area
One wireless monitor can be connected to 4 cameras for simultaneous monitoring

*2.4GHz Advanced Wireless Transmission

With the 2.4G wireless transmission technology, the BM10 baby monitor features faster transmission speed, longer transmission distance, and stronger anti-interference than others.

this technology can greatly reduce power consumption. After fully charged, the screen can be used continuously for 5 hours if the screen is always on.

*VOX (Voice Control) Auto Wake-up Function

If the volume from the baby reaches a certain level, the monitor will be triggered even if is in screen saver mode to inform parents to check on the baby.

VOX (voice control) can be turned on or off, or adjusted to the sensitivity in the setting.

*Super Clear Infrared Night Vision

Equipped with an infrared automatic sensing system, the BM10 baby camera will be triggered when the light is dim. It supports crystal image recording efforts day and night.

*Two-way Communication

it supports real-time intercom. The monitor and camera are both equipped with a microphone and speaker. Just hold the right (intercom) button to speak and transmit. Release the right (intercom) button to receive voice.

*Beautiful Lullabies

Operate the device remotely, the camera will play music automatically. The volume can be adjusted through the wireless monitor.

*Auto Feeding Clock

You could choose OFF/2H/4H/6H in setting to remind of feeding. It's convenient for fresh parents.

*Temperature Monitor and Display

The temperature sensor of the camera detects temperature around your little one and it will be displayed in real time on the corner of 2.45 inch LCD screen. ℃/℉ can be chosen. Keeping knowing if your baby is in a comfortable environment is much important for his/her growth.

Pairing

Select the “Pairing” option, by pressing left/right button to choose how many cams you would connect, then press “OK”. At the same time press the pairing key behind the camera for 3 seconds. When the LED flashes quickly, it means the camera has switched to the pairing state. “OK” appears on the screen to indicate that the pairing was successful.

• The camera and monitor have been paired in advance, you donʼt have to pair them again.
• The volume buttons can only adjust the volume of the monitor (parent unit).
• Baby monitor mount/holder can be offered by contacting us.
• This baby camera is designed for home use only.
• The receiver unit is rechargeable and includes the AC adapter to charge the unit.

• Audio Only Mode - Enjoy More Peace of Mind for Parents

• Press the power button, the LCD display can be a turn-off and the unit will switch to screen saver mode. With the audio-only mode, you could enjoy your own time with more peace of mind. Press and hold the menu/ZOOM button for 3 seconds to ZOOM in and out, more details of your baby will be displayed.
